Description
Transducer Techniques THD-10K-Z 448255 Load Cell Sensor
High-accuracy 10,000 lb capacity load cell sensor designed for industrial force measurement applications.
| Brand | Transducer Techniques |
| Model | THD-10K-Z |
| Voltage | 10 VDC excitation |
| Country of Origin | USA |
| Weight | 1.2 lbs (0.54 kg) |
| Dimensions | 3.5 x 1.5 x 1.0 inches (89 x 38 x 25 mm) |
| Warranty | 1 year limited warranty |
| Certifications | RoHS Compliant, CE Certified |
| SKU / MPN | 448255 |
| What’s in the box | Load cell sensor, mounting hardware, calibration certificate, user manual |
| Capacity | 10,000 lbs (44.48 kN) |
| Output Sensitivity | 2.0 mV/V ±0.1% |
| Accuracy | ±0.03% of full scale |
| Material | Stainless steel |
| Temperature Range | -20°C to 70°C (-4°F to 158°F) |
| Excitation Voltage | 5 to 15 VDC |
Key benefits: Durable stainless steel construction ensures long-term reliability; high accuracy and low hysteresis provide precise measurements; compact design allows easy integration into various systems.
Typical applications: Industrial weighing systems, force measurement in manufacturing, structural testing, and material testing setups.
Order number: Transducer Techniques THD-10K-Z 448255 Load Cell Sensor
Lifecycle: Active
Documentation: Includes calibration certificate and user manual available online.
