Description
TURCK TBEN-L5-8DIP-8DOP-01 IO-Link Master Module
Compact IO-Link master with 8 digital inputs and 8 digital outputs for decentralized automation.
| Brand | Turck |
| Model | TBEN-L5-8DIP-8DOP-01 |
| Voltage | 18-30 VDC |
| Country of Origin | Germany |
| Weight | 0.35 kg |
| Dimensions | 60 x 30 x 200 mm |
| Warranty | 2 years |
| Certifications | CE, cULus, RoHS, IO-Link |
| SKU / MPN | TBEN-L5-8DIP-8DOP-01 |
| What’s in the box | 1 x IO-Link master module, connectors, quick start guide |
| Number of Inputs | 8 digital (PNP/NPN) |
| Number of Outputs | 8 digital (PNP) |
| IO-Link Ports | 4 Class A ports |
| Communication Interface | Ethernet/IP, Profinet, Modbus TCP |
| Operating Temperature | -40°C to +70°C |
| Protection Rating | IP67 |
Key benefits: Multi-protocol support, rugged IP67 housing, easy configuration, reduces wiring costs.
Typical applications: Distributed I/O in manufacturing, material handling, machine building, process automation.
Order number: TURCK TBEN-L5-8DIP-8DOP-01 IO-Link Master Module
Lifecycle: Active
Documentation: User manual and configuration files available on Turck website
