Description
Siemens Frequency Converter 6SE7016-0TP50-Z C23+G91
High-performance Siemens frequency converter designed for precise motor control and energy efficiency in industrial automation.
| Brand | Siemens |
| Model | 6SE7016-0TP50-Z C23+G91 |
| Voltage | 380-480 V AC |
| Country of Origin | Germany |
| Weight | 3.5 kg |
| Dimensions | 190 x 130 x 110 mm (HxWxD) |
| Warranty | 2 years |
| Certifications | CE, UL, RoHS |
| SKU / MPN | 6SE7016-0TP50-Z C23+G91 |
| What’s in the box | Frequency converter unit, mounting hardware, user manual |
| Power Rating | 1.5 kW (2 HP) |
| Output Frequency | 0 to 500 Hz |
| Control Type | Vector Control (Sensorless) |
| Communication Interface | PROFIBUS DP |
| Cooling Method | Convection cooling |
| Operating Temperature | -10°C to +50°C |
| IP Rating | IP20 |
Key benefits: Provides precise speed and torque control for AC motors, enhances energy efficiency, reduces mechanical stress, and supports easy integration with industrial automation systems.
Typical applications: Used in conveyor systems, pumps, fans, compressors, and other industrial motor-driven equipment requiring variable speed control.
Order number: Siemens Frequency Converter 6SE7016-0TP50-Z C23+G91
Lifecycle: Active product with ongoing support and availability.
Documentation: User manual, installation guide, and technical datasheets available on Siemens official website.
