🔍 Hover to zoomHigh-purity pneumatic diaphragm valve engineered for precision fluid control in critical process applications with exceptional chemical resistance and leak-tight performance.
| Brand | FUJIKIN |
| Model | LAM766-077821-103 |
| Voltage | 24V DC (pneumatic actuator) |
| Country of Origin | Japan |
| Weight | 2.8 kg |
| Dimensions | 120 x 90 x 180 mm |
| Certifications | CE, ISO 9001, SEMI, FDA-compliant materials |
| SKU / MPN | LAM766-077821-103 |
| What’s in the box | Diaphragm valve, actuator, mounting brackets, installation manual, calibration certificate |
| Valve Type | Pneumatic Diaphragm Valve |
| Body Material | Stainless Steel 316L |
| Diaphragm Material | PTFE (EPDM backup) |
| Connection Type | Flanged / Weld ends |
| Pressure Rating | 0 to 10 bar |
| Operating Temperature | -10°C to +180°C |
Key benefits: Superior chemical compatibility, leak-tight shutoff, high cycle life, low particle generation, compact actuator design, easy maintenance
Typical applications: Semiconductor wet process, pharmaceutical manufacturing, ultra-pure water systems, chemical dosing lines, biotech fluid handling, CIP/SIP systems
Lifecycle: Active product with 15+ years availability, long-term spare parts support
