π Hover to zoomCompact and efficient pneumatic vacuum generator for precise pick-and-place automation tasks
| Brand | KGN |
| Model | KVM-S607-T |
| Voltage | 24V DC |
| Country of Origin | China |
| Weight | 0.15 kg |
| Dimensions | 75 x 45 x 30 mm |
| Warranty | 12 months |
| Certifications | CE, RoHS |
| SKU / MPN | KVM-S607-T |
| Whatβs in the box | Mini Vacuum Generator, mounting bracket, quick connectors, user manual |
| Maximum Vacuum Pressure | -88 kPa |
| Operating Air Pressure | 0.4 β 0.7 MPa |
| Air Consumption | 22 L/min |
| Nozzle Diameter | 0.7 mm |
| Port Size | PT 1/8 inch |
| Response Time | β€ 25 ms |
Key benefits: Lightweight design, rapid vacuum response, low air consumption, easy installation, reliable suction performance, compatible with standard pneumatic systems
Typical applications: Pick-and-place robots, surface mount technology (SMT), electronic component handling, packaging lines, small parts transfer, automated assembly stations
Lifecycle: Active product, expected 8+ years availability with ongoing support
