π Hover to zoomReliable point level detection for liquids, unaffected by foam, turbulence or changing media properties
| Brand | VEGA |
| Model | SWING61.XXGBVXPNX |
| Voltage | 24V DC |
| Country of Origin | Germany |
| Weight | 0.8 kg |
| Dimensions | 120x80x60 mm |
| Warranty | 24 months |
| Certifications | CE, ATEX, IECEx, SIL2 |
| SKU / MPN | SWING61.XXGBVXPNX |
| Whatβs in the box | Vibrating fork level switch, mounting bracket, product manual, safety instructions |
| Process Connection | G1/2 thread |
| Process Temperature | -40Β°C to +150Β°C |
| Process Pressure | -1 to 64 bar |
| Output Signal | PNP/NPN transistor, relay |
| Housing Material | Stainless steel 316L |
| Protection Class | IP66/IP67 |
Key benefits: No moving parts, low maintenance, high chemical resistance, SIL2 certified for safety applications, easy setup with plug-and-play installation
Typical applications: Overfill protection in tanks, pump dry-run protection, leak detection, level control in chemical, food, and water industries
Lifecycle: Active product, 10+ years availability
