🔍 Hover to zoomHigh-precision draw-wire displacement sensor with RS485 output for reliable linear position measurement in industrial environments
| Brand | Mirad |
| Model | MPS-XS-R-1000MM-RS485 |
| Voltage | 24V DC |
| Country of Origin | Germany |
| Weight | 0.8 kg |
| Dimensions | 120 x 80 x 60 mm |
| Warranty | 24 months |
| Certifications | CE, RoHS, IP65 |
| SKU / MPN | MPS-XS-R-1000MM-RS485 |
| What’s in the box | Draw-wire sensor unit, mounting brackets, M12 connector, calibration certificate, user manual |
| Measurement Range | 0-1000 mm |
| Output Signal | RS485 (Modbus RTU) |
| Resolution | 0.1 mm |
| Linearity | ±0.1% of full scale |
| Protection Class | IP65 |
| Operating Temperature | -20°C to +80°C |
Key benefits: 1000mm measurement range, robust IP65 housing, RS485 Modbus RTU communication, high resolution of 0.1mm, excellent linearity, compact XS form factor, easy integration with PLCs and SCADA systems
Typical applications: Hydraulic cylinder position monitoring, crane and hoist positioning, conveyor belt tracking, automated machinery stroke measurement, valve position feedback, construction equipment, material handling systems
Lifecycle: Active product, expected 7-10 years availability with full support
