π Hover to zoomHigh-precision IFM incremental encoder for reliable speed and position feedback in demanding industrial environments
| Brand | IFM |
| Model | RB6029 |
| Voltage | 4.75-30V DC |
| Country of Origin | Germany |
| Weight | 0.4 kg |
| Dimensions | 58x58x58 mm |
| Warranty | 24 months |
| Certifications | CE, UL, RoHS, cULus |
| SKU / MPN | RB6029 |
| Whatβs in the box | Incremental Encoder RB6029, Mounting hardware, Installation manual |
| Output Signal | HTL / Push-Pull |
| Resolution | Up to 5000 ppr |
| Shaft Type | Solid shaft, 6 mm |
| Protection Class | IP65 |
| Shaft Load | Axial 20 N / Radial 40 N |
| Operating Temperature | -20 to 85 Β°C |
Key benefits: Robust IP65 housing, wide supply voltage range, high resolution up to 5000 ppr, solid shaft design, German engineering quality, long-term reliability
Typical applications: Conveyor belt speed monitoring, motor feedback control, packaging machinery, printing equipment, textile machines, material handling systems
Lifecycle: Active product, long-term availability supported by IFM
