Description
DODE Phase Monitoring Relay BA9041 Electrical Safety Device
Reliable phase monitoring relay designed to protect three-phase electrical systems from phase failure, phase sequence errors, and voltage imbalance.
| Brand | DODE |
| Model | BA9041 |
| Voltage | 3x 380-480V AC |
| Country of Origin | Germany |
| Weight | 0.25 kg |
| Dimensions | 90 x 35 x 65 mm (HxWxD) |
| Warranty | 2 years |
| Certifications | CE, UL, RoHS |
| SKU / MPN | BA9041 |
| What’s in the box | Phase Monitoring Relay BA9041, User Manual, Mounting Accessories |
| Phase Monitoring Range | 320V to 520V AC |
| Response Time | ≤ 200 ms |
| Output Contact | 1 changeover relay contact (8A, 250V AC) |
| Operating Temperature | -20°C to +60°C |
| Mounting Type | DIN Rail |
| Protection Features | Phase failure, phase sequence, phase asymmetry |
| Power Consumption | Approx. 3 VA |
Key benefits: Ensures safe operation of three-phase motors and equipment by detecting phase faults quickly to prevent damage and downtime.
Typical applications: Industrial motor protection, HVAC systems, pump control panels, and electrical distribution boards.
Order number: DODE Phase Monitoring Relay BA9041 Electrical Safety Device
Lifecycle: Active
Documentation: User manual and wiring diagrams available upon request
