DEIF Module PCM5.1 – Advanced Power Management Solution
Advanced power management module for generator set control, offering precise load sharing and monitoring.
| Brand | DEIF |
| Model | PCM5.1 |
| Voltage | 24V DC (8-36V DC range) |
| Country of Origin | Denmark |
| Weight | 0.3 kg |
| Dimensions | 100 x 80 x 40 mm |
| Warranty | 2 years |
| Certifications | CE, DNV GL, EMC, Marine type approval |
| SKU / MPN | PCM5.1 |
| What’s in the box | PCM5.1 module, mating connectors, mounting bracket, quick start guide |
| Power Supply | 8-36V DC, typical 24V DC, <5W consumption |
| Communication | CAN bus (CANopen/J1939), USB, RS-485 |
| Analog Inputs | 4 configurable (0-10V, 4-20mA, Pt100, etc.) |
| Digital I/O | 6 digital inputs, 4 digital outputs (relay/solid state) |
| Operating Temperature | -25°C to +70°C |
| Protection Rating | IP20 (enclosed in panel) |
Key benefits: Reduced fuel consumption, seamless parallel operation, intuitive software, robust marine-grade design.
Typical applications: Marine generators, standby power plants, peak shaving systems, remote monitoring of gensets.
Order number: DEIF Module PCM5.1 – Advanced Power Management Solution
Lifecycle: Active
Documentation: DEIF PCM5.1 datasheet, installation manual, configuration software ALC-2
Typical applications: Marine generators, standby power plants, peak shaving systems, remote monitoring of gensets.
Order number: DEIF Module PCM5.1 – Advanced Power Management Solution
Lifecycle: Active
Documentation: DEIF PCM5.1 datasheet, installation manual, configuration software ALC-2
