Description
Datalogic Matrix 320 Industrial Barcode Reader Model 705-330
High-performance industrial barcode reader designed for fast and accurate 1D and 2D code scanning in harsh environments.
| Brand | Datalogic |
| Model | Matrix 320 Model 705-330 |
| Voltage | 24 V DC |
| Country of Origin | Italy |
| Weight | Approx. 1.2 kg (2.65 lbs) |
| Dimensions | 150 mm x 150 mm x 150 mm (5.9″ x 5.9″ x 5.9″) |
| Warranty | 2 years limited warranty |
| Certifications | CE, UL, FCC, RoHS |
| SKU / MPN | 705-330 |
| What’s in the box | Matrix 320 barcode reader, mounting bracket, power and communication cables, user manual |
| Scan Technology | Area Imager (2D and 1D barcode reading) |
| Resolution | 1280 x 1024 pixels |
| Reading Distance | Up to 500 mm (19.7 inches), depending on barcode size and type |
| Interface Options | Ethernet, RS-232, USB |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| IP Rating | IP65 (dust and water resistant) |
| Light Source | White LED illumination |
Key benefits: Robust design suitable for industrial environments, fast decoding of a wide range of barcode symbologies, easy integration with multiple interfaces, and high reliability for continuous operation.
Typical applications: Manufacturing line tracking, warehouse inventory management, logistics and shipping verification, and automated quality control systems.
Order number: Datalogic Matrix 320 Industrial Barcode Reader Model 705-330
Lifecycle: Active product with ongoing support and firmware updates
Documentation: User manual, installation guide, and software development kit available on Datalogic website
