🔍 Hover to zoomReliable 4-20mA vibration transmitter for continuous machinery condition monitoring in harsh industrial environments
| Brand | METRIX |
| Model | ST5484E-156-0134-00 |
| Voltage | 24V DC |
| Country of Origin | USA |
| Weight | 0.9 kg |
| Dimensions | 120 x 80 x 60 mm |
| Warranty | 24 months |
| Certifications | CE, ATEX, IECEx, CSA |
| SKU / MPN | ST5484E-156-0134-00 |
| What’s in the box | Vibration transmitter, mounting hardware, calibration certificate, user manual |
| Output Signal | 4-20 mA proportional to vibration |
| Frequency Range | 2 Hz to 2000 Hz |
| Sensitivity | 100 mV/g |
| Power Supply | 24V DC nominal |
| Housing Material | Stainless steel |
| Operating Temperature | -40°C to +85°C |
Key benefits: Loop-powered operation, high accuracy vibration measurement, rugged stainless steel construction, hazardous area certified, simple integration with PLC/DCS systems
Typical applications: Rotating equipment monitoring on pumps, motors, fans, compressors, and turbines in oil and gas, power generation, and process industries
Lifecycle: Active product with long-term availability and global support
