Broadcom Avago 9306-24i SATA / SAS HBA Controller 12Gbps IT-Mode 24port LSI ZFS
High-performance 24-port 12Gbps SATA/SAS HBA controller optimized for IT mode and ZFS compatibility.
| Brand | Broadcom |
| Model | 9306-24i |
| Voltage | 12V DC |
| Country of Origin | Malaysia |
| Weight | 0.3 kg |
| Dimensions | 6.6 x 2.7 x 0.9 inches (168 x 69 x 23 mm) |
| Warranty | 3 years limited |
| Certifications | CE, FCC, RoHS |
| SKU / MPN | 9306-24i |
| What’s in the box | HBA Controller Card, Low-profile bracket, Quick installation guide |
| Interface | PCIe 3.0 x8 |
| Ports | 24 internal SATA/SAS ports |
| Data Transfer Rate | 12Gbps per port |
| Mode | IT Mode (Initiator Target) |
| Compatible RAID | Non-RAID (HBA mode) |
| Supported Protocols | SAS-3, SATA III |
<
div class=”info-box”>
Key benefits: Enables direct disk access with minimal overhead, ideal for ZFS and software-defined storage solutions; supports
