Description
SIEMENS Torque Motor 1FW6190-0WB15-2JC3 for High Torque D…
High-performance torque motor for direct drive applications, offering precision and reliability in demanding industrial environments.
| Brand | SIEMENS |
| Model | 1FW6190-0WB15-2JC3 |
| Voltage | 400V AC |
| Country of Origin | Germany |
| Weight | 45 kg |
| Dimensions | 300 x 300 x 400 mm |
| Warranty | 2 years |
| Certifications | CE, UL, ISO 9001 |
| SKU / MPN | 1FW6190-0WB15-2JC3 |
| What’s in the box | 1 x Torque Motor, 1 x Connector Kit, 1 x Installation Guide |
| Rated Torque | 120 Nm |
| Rated Speed | 500 rpm |
| Protection Class | IP54 |
| Cooling Method | Natural convection |
| Insulation Class | F |
| Shaft Type | Solid shaft with keyway |
Key benefits: High torque density, compact design, low maintenance, excellent dynamic response
Typical applications: Machine tools, robotics, printing presses, packaging machinery
Order number: SIEMENS Torque Motor 1FW6190-0WB15-2JC3 for High Torque D…
Lifecycle: Active
Typical applications: Machine tools, robotics, printing presses, packaging machinery
Order number: SIEMENS Torque Motor 1FW6190-0WB15-2JC3 for High Torque D…
Lifecycle: Active
