Description
The Woodward 5464-658 is a digital speed sensor module that provides accurate and reliable speed measurement for a variety of industrial applications. It features four channels that can be used with passive magnetic pickup units (MPUs) or proximity probes, and it supports a wide range of speed frequencies from 0.5 to 25,000 Hz. The module also includes a filter that can be adjusted to minimize noise and improve accuracy.
Key Features
Four channels for MPUs or proximity probes
Wide speed range (0.5 to 25,000 Hz)
Adjustable filter
16-bit resolution
High accuracy
Reliable performance
Technical Specifications
Input frequency: 0.5 to 25,000 Hz
Input amplitude: 3.5 to 32 Vdc input to the module
Available power: 12 Vdc or 24 Vdc
Output: 0 to 10 Vdc
Resolution: 16 bits
Accuracy: ±0.1% of full scale
Repeatability: ±0.02% of full scale
Noise: <0.01% of full scale
Isolation voltage: 0 Vrms
Fuse: 24 Vdc 100 mA fuse/channel, 12 Vdc short circuit protected
Time Stamping: 5 millisecond resolution on low event and low latch
Applications
The Woodward 5464-658 can be used in a variety of industrial applications where accurate speed measurement is critical, such as:
Gas turbines
Turbochargers
Pumps
Fans
Compressors
Wind turbines
Robotics
