7MF4433-1DA02-2AB1

7MF4433 – measuring pressure converter Sitrans p ds III for
differential pressure and consumption, output signal 4 … 20 mA, HART
protocol, static pressure PN32/160, 1 – filling the measuring cell: silicone
oil, conventional cleaning; D is the nominal measurement range 250 MBAR,
static pressure 160 bar; A – stainless steel membrane material. Steel, the
material of the hull of the sensor stainless steel. Steel, 0 – connection to
the process: oval flange: stainless steel material. Steel, PN 160, mounting
thread: M10, 2-aluminum, painted, 2-international execution, inscription in
English, documentation on the CD-disk, a-without explosion protection,
b-cable input with M20 x 1.5 thread, 1-LCD, cover without an observation
window, cover, cover 7MF4433-1DA02-2AB1
