7MF1565-3BA00-1AA1

7MF1565 – measuring pressure converter Sitrans P200 for excess
or absolute pressure, error 0.25%, measuring membrane material: ceramics,
material of the converter case and measuring cell: stainless steel. Steel,
measurement range for excess pressure: from 0 to 1 bar, overload pressure 2.5
bar output: 4–20 m two-wire connection, DC power from 7 to 33 V without
explosion protection Electric connection: STETER on DIN EN 175301-803-A,
thread for the stuffing oil sewn M16 (with a connector) connection to the
process: G1/2 External in EN 837-1 (1/2 BSP external) (standard for metric
pressure ranges in MBAR, bar) BECTION Material between the sensor and the
case: Viton (FPM, standard) Standard performance 7MF1565-3BA00-1AA1
