7MF0310-1DL01-5AF2-Z A01 B30 E00 H01 Y01

Sitrans P320 pressure transducer (without primary verification
and metrological certificate) relative pressure (vicin. Cells: silicone oil
max. Measurement interval: 60 MBAR (24.11 mm H2O) ovaln. flan., fastener
thread: 7/16-20 UNF (IEC 61518) Technol. Soy.: ​​Stainless. Art. 316L/1.4404,
separation membrane: stainless steel. Art. 316L/1.4404; Diff sensor.
Pressure: Technol. Flain: Stainless. Art. 316/1.4408 Corps from aluma., Cast.
Under pressure, a two -chamber device without explosion protection 2 x m20 x
1.5 with a display (a cover with glass) includes a cable oil seal, metal
passport plate English – the overall tolerance for explosive zones: globally
(CE, RCM) except: EAEU, FM, CSA, KCC, KCC, KCC, steel, steel galvanic Osink.
Setting up of the measurement range: beginning of measurement (max. 5 ts.);
end of the measurement (max. 5 zn.); unit (MBAR, BAR, KPA, MPa, PSI …)
Example: -0.5 & 10.5 psi 7MF0310-1DL01-5AF2-Z A01 B30 E00 H01
Y01{Y01:-100…100mmH20}
